Hantek 1008C PC USB 8CH Automotive Diagnostic Digital Oscilloscope/DAQ/Programmable Generator

• 2.4MSa/s, 12bits;
• DAQ card function;
• Cost-effective 8 channels oscilloscope for vehicle testing;
• 8 channels programmable generator which can analog signals of crankshaft, camshaft etc.

Product introduction：

100MHz, 8 channels oscilloscope for vehicle testing. Over 80 types of automotive diagnostic function (​Ignition/Sensor/Bus detection/Performe/Starter and charging circuits etc.)​. Video Help Function, provides the video help of diagnostic which can be watching online, The diagnostic result can be generated diagnostic report., printed or taken screenshot by pushing one key, many methods to save the data. Supported to record waveform for a long time. It can simulate camshaft and crankshaft signal. Transmit signals through USB 2.0 interface plug and play, and no need extra power supply.

PC software only supports windows7/8/10 32-bit and 64-bit, do not support OS

Function Selection

There are three functions of vehicle diagnosis, oscilloscope and signal generator, including 78 types of vehicle diagnosis function.

Multilanguage Support

Support the display surface in Chinese, English, German language, and it can be switched freely.

Reference Waveform

Over 80 types of standard reference waveform inside and can be callout or close with one button. It is convenient to be compared.

Measurement Method

20 types of automatic measurement method which can be callout or close with one button. It is convenient and visual to read out the result.

One Button Screenshot

Save the current waveform and generate pictures. Storage location is optional and easy to find.

Quick Guide

Callout the quick guide column with one button. There are special vedio guide for each vehicle diagnosis function, including wiring method, adjustment method, reference waveform etc. And it is supported to be checked through scanning the QR code.

Print

The result can be printed with one button and generate diagnosis report which is easy to be saved and recorded.

REF Comparison Waveform

The user can save the waveform as REF format and callout it again when you need to compare the two waveforms catched in different time.

Data Storage

The diagnosis result can be saved as the format of txt, csv, rfc, xls, doc, jpg and etc. It is convenient to be checked and compared later.

8CH Vehicle Diagnosis 8CH signal can be measured simultaneously. The measurement voltage of each channel can be adjusted independently. You can choose to open or close each channel.

Waveform Record Support to record and replay the waveform. The waveform can be save into the computer hard disk and easy to read. There is no limit to the record time which can long-time measure and record the waveform for troubleshooting.

Cursor Measurement Support 4 types of cursor measurement mode -cross,track, horizontal, and vertical.It’s easy to read out the time and voltage of irregular signal.

Color and Lightness The background color is optional as user’s preference. And the lightness of waveform and gridding is settable.

USB Communication USB2.0 power supply + communication interface, plug and play, and support hot plugging.

Signal Generator Signal generator function, can simulate crankshaft and camshaft signal.
