Hantek DSO5102P USB Storage Oscilloscope Oszilloskope 2 Channels 100MHz 1GSa/s

Hantek DSO5102P Digital Oscilloscope 100MHz 2Channels 40K 1GSa/s Real Time Sample Rate USB Host and Device Connectivity 7 Inch

• Remote Control and U Disk Storage: Hantek DSO5102P oscilloscope can store more than 1000 waveforms information, and can upgrade the system through the USB port, support plug-and-play USB storage devices and communicate with the computer and remote control through USB.
• measure AC/DC Voltage and Current, Resistance, Diode, Continuity Buzzer
• Large TFT LCD Display: Large 7-inch 64K color TFT LCD display with a resolution of 800 * 480. It can clearly show any measured alternating current, including sine, square, sawtooth and triangular waves.
• A RS232C or USB standard serial port, data hold, relative mode,
• Customer Service – If you have any questions about our product and service, please contact our after-sales customer service as soon as possible, we will solve it for you as soon as possible.

Specification:

Model: DSO5102P

Sample Rate: Real-Time Sample: 1GS/s;

Equivalent Sample: 25GS/s;

Average: Wavefom Average, selectable 4,8,16,32,64,128;

Inputs Coupling: AC, DC, GND;

Inpits Impendance: 1MΩ±2% ‖20pF±3pF;

Probe Attenuation: 1X, 10X;

Supported Probe Attenuation Factor: 1X, 10X, 100X, 1000X;

Horizontal

Sample Rate Range: 500MS/s–1GS/s

Waveform Interpolation: (sin x)/x

Record Length: 40K

SEC/DIV Range: 2ns/div to 80s/div

Sample Rate and Delay Time Accuracy: ±50ppm（at over any ≥1ms time interval)

Vertical

Vertical Resolution: 8-bit resolution, all channel sampled simultaneously;

Bandwidth：100MHz；

Rise Time at BNC( typical)：3.5ns;

Math： +, -, *, /, FFT;

FFT: Windows: Hanning, Flatop, Rectamgular, Bartlett, Blackman;1024 sample point

Bandwidth Limit: 20MHz

• 100MHz bandwidths;
• 1GSa/s Real Time sample rate;
• Large (7.0-inch) color display,WVGA(800×480);
• Record length up to 40K;
• Trigger mode: edge/pulse width/line selectable video/slop/overtime etc;
• USB host and device connectivity, standard;
• Multiple automatic measurements;
• Four math functions, including FFTs standard.
